Yuchai YCF135S
1.New generation products
2.Chinese Ill emission
3.Advanced hydraulic system
4.Durable metal covering panels
5.Safe and comfortable cab
6.Reliable and durable structural
YCF135s skidder,can be equipped with 21, 23 and 25m telescopicarms. It can easily gather the wood together within the working range,working on the hillside below 75 degrees with high efficiency.
Performance Parameters
|
Chain saw |
||
|
Chainsaw maximum cutting diameter |
mm |
350 |
|
Guide bar length |
mm |
457.2(18 in) |
|
Chain pitch |
mm |
0.404 |
|
Capacity of chain oil tank bar |
L |
3.4 |
|
Feeding |
||
|
Rollers quantity |
2 |
|
|
Rollers diameter |
mm |
371 |
|
Max. opening of rollers |
mm |
400 |
|
Max. feed force |
KN |
16 |
|
Max. feed speed |
m/s |
0~4.1 |
|
Delimbing knife |
||
|
Knives qty |
2+1 |
|
|
Diameter tip-to-tip |
mm |
330 |
|
Front knives max. opening |
mm |
480 |
|
Rear knives max. opening |
mm |
/ |
|
Hydraulic requirement |
||
|
Operating hydraulic |
MPa |
25 |
|
Flow required |
L/min |
150~180 |
|
Power required |
KW |
40~60 |
|
Operating vdtage |
V |
24 |
|
Control system |
YUCHAI |
|
|
Application |
||
|
For Excavator |
T |
8~15 |
|
Technical specification |
||
|
Width(head closed/head open) |
mm |
870/1130 |
|
Length |
mm |
1140 |
|
Height |
mm |
1100 |
|
Weight |
kg |
600 |
